Product Description
1.2mm Stainless steel material, With imported Olympia Burner from Japan, Schneider Electronic elements, CAHO Temperature controller from Taiwan
Suit for food factory, large chain stores and other large quantities of baking.
Available for food : Moon Cake, Toast, All kinds of bread, Hamburg, All kinds of snacks, biscuits, meats, etc.
Product Characteristics
Heating system: High efficiently hot air convection system makes fire to be more uniform.
Air channel: Unique design, uniform wind.
Uniformity: Strong wind convection helps fire heating be more uniform.
Durability: Perfect design for structure heat insulation low malfunction more durable.
Easy operation：Labor saving and just need one person operating entire cart in and
Out using “OLYMPIA” Japan burner, “CAHO” Taiwan temperature controller.
The door double-layer tempered glass door, simple and convenient.
Five stage style tuyere, facilitate adjustment furnace temperature.
The oven is removable structure, conveniently to transport and install.
With the exhaust system
With the steam function can be baking the french Baguette
Data Sheet
Model | Specification | Dimension（mm) | Voltage | Power | Power Consumption | Temperature range | Power Source |
HG-16D | 16 Trays | 1400*2235*2420 | 380V | 32kw | 32kw/h | 20℃~300℃ | Electric |
HG-32D | 32 Trays | 1660*2600*2420 | 380V | 46kw | 46kw/h | 20℃~300℃ |
HG-64D | 64 Trays | 2008*2885*2420 | 380V | 72kw | 72kw/h | 20℃~300℃ |
HG-16Y | 16 Trays | 1400*2235*2420 | 380V | 3kw | 5L/h | 20℃~300℃ | Diesel |
HG-32Y | 32 Trays | 1660*2600*2420 | 380V | 3kw | 7.5L/h | 20℃~300℃ |
HG-64Y | 64 Trays | 2008*2885*2420 | 380V | 3kw | 15L/h | 20℃~300℃ |
HG-16Q | 16 Trays | 1400*2235*2420 | 380V | 3kw | 5m³/h | 20℃~300℃ | Gas |
HG-32Q | 32 Trays | 1660*2600*2420 | 380V | 3kw | 7.5 m³/h | 20℃~300℃ |
HG-64Q | 64 Trays | 2008*2885*2420 | 380V | 3kw | 15 m³/h | 20℃~300℃ |
